Acute radial head replacement with bipolar prostheses: midterm results

Acute radial head replacement with bipolar prostheses: midterm results

Nosenzo, A., Galavotti, C., Menozzi, M. et al. Acute radial head replacement with bipolar prostheses: midterm results. Eur J Orthop Surg Traumatol 31, 309–318 (2021). https://doi.org/10.1007/s00590-020-02774-4

Abstract

In irreparable radial head fractures, especially if primary stabilizers of the elbow are damaged, the prosthetic replacement prevents instability and stiffness. Concerns have arisen over the use of bipolar press-fit prostheses due to the frequent finding of osteolysis and the risk of instability if compared to monopolar implants. Our aim was to assess midterm clinical and radiological outcomes of bipolar implants and the influence of osteolysis on proximal pain. Seventeen patients with irreparable fractures of the radial head, treated in acute with the same prosthetic model (rHEAD recon SBI/Stryker) between January 2015 and December 2018, were enrolled. Clinical assessment was performed using MEPS and DASH scores; a radiographic study was done to identify heterotopic ossifications and periprosthetic osteolysis. Outcomes at the last follow-up, according to MEPS, were excellent in 10 cases, good in 5 and fair in 2; none of the patients had severe pain or instability. In 3 cases, it was necessary to remove the implant, mainly because of early loosening. Radiological findings of osteolysis were detected in 9 cases, but no statistical correlation was found with MEPS and proximal pain. The use of bipolar implants is reliable if an accurate repair of ligament tears is performed and provides a good stability. Nevertheless, the risk of early aseptic loosening in uncemented implants is not negligible, and the follow-up of the patient must be strict. Late osteolysis does not seem to have clinical relevance, but further prospective studies are necessary to clarify this topic.

Introduction

Radial head influence on the elbow stability as secondary stabilizer by resisting to valgus stress and on the prevention of posterolateral rotatory instability is well understood [12]. When primary stabilizers such as the coronoid, lateral (LCL) and medial collateral ligaments (MCL) are damaged, the integrity of the radial head takes on a predominant role and must be preserved [3]; consequently, in comminuted and displaced fracture (Mason type III and Mason type IV), if an anatomical reconstruction is not a viable solution, the prosthetic replacement should always be performed [4,5,6]. Radial head arthroplasty allows the injured soft tissues acting as major stabilizers to heal properly by the restoration of the native radial length, decreases the edge loading thus preventing cartilage wear and the onset of osteoarthritis and reproduces radiocapitellar kinematics [7]. Modern radial head prostheses (RHP) try to re-establish the native radio-humeral contact during the entire range of motion in order to avoid stiffness, pain and capitellar erosion. Three different strategies have been adopted to achieve this goal; loose-fit stems with a self-centering mechanism that decreases the incongruences between the implant and capitellum/lesser sigmoid notch, RHP with anatomic radial head replicating as much as possible the native anatomy and bipolar RHP that allows a rotation between the neck and the head of 10–15 degrees in all the planes, thus solving the problem of the great variability of head–neck angles with an adaptive positioning of the implant. When they were first introduced by Judet in 1996, bipolar RHP had a long and cemented stem; conversely, more recent implants have anatomical and press-fit short stems.

Concerns have arisen over both the effect of the bipolarity on elbow stability that seems to be reduced if compared to monopolar implants and the wear of the polyethylene used between the stem and the radial head [89]. Moreover, osteolysis with loosening of metallic press-fit stems seems to be a common finding but its clinical relevance is still unclear and controversial [10]. Our primary aim was to investigate the midterm clinical and radiological outcomes of bipolar prostheses in irreparable radial head fractures and subsequently to examine the impact of osteolysis both on proximal forearm pain and on the survival of implants.

Materials and methods

This is a retrospective single-center study performed at the department of Orthopedic Surgery. A research in the surgical database with the following inclusion criteria was performed in December 2019: patient with irreparable acute fracture of the radial head, implant of a bipolar radial head prosthesis with short press-fit stem (rHEAD recon SBI/Stryker, Morrisville, PA, USA) performed by our senior author (F.C) between January 2015 and December 2018. Exclusion criteria were: previous ipsilateral surgery, chronic injuries. Twenty-two patients met the inclusion criteria, and demographic data were collected. Surgical records were analyzed by a trained Orthopaedic surgeon (C.G), investigating concomitant bony lesions and ligamentous injuries, use of cementation, associated surgical procedures and intra-operative complications such as massive bleeding or residual instability of the elbow. The preoperative CT scans and plain radiographs were investigated separately by two residents in Orthopaedic Surgery (A.N/M.M) allowing to identify the pattern of radial head fracture according to modified Mason classification [11], presence of coronoid fracture or other patterns of ulnar fractures [1213]; any discordances were discussed and solved by the senior author (F.C). Patients were subsequently convened to the follow-up evaluation. A clinical assessment was performed using the Mayo Elbow Performance Score (MEPS) and The Disabilities of Arm, Shoulder and Hand score (DASH score); any further surgery following the primary implant was recorded. Afterward, a radiographic study with standardized anteroposterior, oblique and lateral views of the affected elbow was carried out and images were analyzed (C.G). Heterotopic ossifications were graded from I to IV using Ilahi and Gabel system [14], presence of osteolysis and radiographic loosening around the stem were assessed with Morrey grading scale (Table 1) [15]. Plain radiographs at the final follow-up were compared with radiographs performed at the last ordinary postsurgical follow-up in order to point out the evolution in time of osteolysis. Data were statistically analyzed with the commercial package IBM SPSS Statistics (IBM Corp., Armonk, NY, USA); statistical summaries were obtained for all the variables. Linear correlations using Pearson correlation coefficient were calculated to identify predictive factors of worse MEPS, range of motion and pain and predictive factors of instability (age, gender, side and type of fracture, associated lesions of the elbow, presence of heterotopic ossifications). A further Pearson correlation coefficient was calculated to point out a possible relationship between the grade of osteolysis and clinical outcomes (MEPS, DASH score, pain, instability, range of motion). The relationship was considered strong for r > 0.7 and r < − 0.7; the results were considered statistically significant for p value < 0.05. All procedures performed involving human participants were in accordance with the ethical standards of the Italian national bioethics committee, and the study was approved by the Regional Ethic Committee with number of protocol 11396.Table 1 Morrey grading system of periprosthetic osteolysis and radiographic loosening [15]Full size table

Results

Out of 22 patients that met the inclusion criteria, 5 were lost at the follow-up: Three were not traceable to the contact detail left and all other attempts were unsuccessful, whereas two did not give availability to further inspection. The final sample was made up of 17 patients, 10 males and 7 females with a mean age at the time of the surgery of 56 years (range 31–74 years). At preoperative plain radiographs, 9 radial head fractures were classified as Mason type IV and 8 as Mason type III with concomitant bony injuries in 11 cases (65%). According to surgical records, ligamentous injuries were detected in 10 cases and repaired in 8 cases (Table 2); the 17 rough-stem implants were press-fitted in 9 patients and fixed with cement in 8 cases when the fit was felt to be inadequate based on the assessment of the senior surgeon. The clinical results at the last follow-up (average 27.7 months, range 12–48) according to MEPS were excellent in 10 cases, good in 5 and fair in 2 with a mean MEPS of 91.2 points (range 70–100) and a mean DASH score of 6.6 points (range 0–34.1); average active flexion was 132° (range 105°–140°); average active extension deficit was 17° (range 0°–60°); average active pronation was 81° (range 10°–90°); average active supination was 74° (range 5°–90°). Twelve patients had no residual pain, 4 had mild, and only 1 had moderate proximal forearm pain. None had gross instability. Further surgery was necessary in 5 cases with an overall re-surgery rate of 29.4%. Due to severe proximal pain after surgery and radiological findings of early loosening of the stems, 2 press-fitted non-cemented bipolar RHPs were removed at 2 months, despite the surgeon had not reported any abnormalities during the primary operation. Because of elbow dislocation with gross instability, in 1 patient it was necessary the hardware removal and to place a dynamic hinged external fixator after considering advanced age and critical general conditions (Fig. 1). One patient, who sustained a terrible triad injury with concomitant fracture of humeral condyle, had the elbow dislocated at the ordinary follow-up at 1 month and was treated with a dynamic hinged external fixation. A case of terrible triad required a ligament revision with further suture anchors for both medial and lateral symptomatic instability. The overall implant removal rate was 17.6% (3/17) with no case of replacement of the implant or disassembling. At last follow-up, heterotopic ossifications were observed in 10 out of 17 patients (59%), classified as Ilahi–Gabel grade I in 2 cases, grade II in 4 and grade IV in 4. Radiological finding of osteolysis, visible as radiolucencies around the stem, was detected in 9 out of 14 cases (64%) excluding cases with the early removal of the prosthesis; according to Morrey, osteolysis was classified as type 0 in 5 patients, type I in 2, type II in 2, type III in 1 and type IV in 4. The temporal evolution of osteolysis between the postoperative follow-up, and the last follow-up is shown in Table 2; both patients with early aseptic loosening of the stem were classified as Morrey type IV at early postoperative follow-up. Statistical analysis with Pearson R test did not prove any strong positive or negative linear dependence between variables, finding no predictive factors of worse MEPS, pain or instability. Moreover, the amount of osteolysis showed just a weak negative linear correlation with MEPS (R = − 0.232) and a weak positive linear correlation with proximal forearm pain (R = 0.252) resulting in nonsignificant p value for confidence interval of 95%.Table 2 Data of the patientsFull size table

figure1
Fig. 1

Discussion

Biomechanical studies have shown the role of radial head in avoiding valgus and longitudinal instability, thus contributing to increase the rate of prosthetic replacement compared to simple radial head excision [21617]. On the contrary, there is still little agreement on the reliability of several prosthetic devices that differ from each other for the features of the head (anatomic, non-anatomic, monopolar, bipolar), the design of the stem (loose-fit, press-fit, short or long), the type of fixation (cemented, uncemented) and the presence of modularity. Conflicting and controversial studies in the recent literature have consequences on daily surgical activity, making it difficult to choose a prosthetic model that ensures satisfactory clinical results, ease of implantation and low failures rate; this study originates from the need to evaluate outcomes, reliability and weaknesses of a single bipolar RHP (rHEAD recon SBI/Stryker, Morrisville, PA, USA), pointing out the rate of failure and the possible association between radiological signs and clinical findings. The theoretical advantage of bipolar prosthesis is a better radiocapitellar congruency due to the triaxial rotation of the head–neck system, thus decreasing the contact pressures on the capitulum during flexion–extension and prono-supination and the stress at the interface implant-bone during the forearm rotation; the prevention of the wear of the articular cartilage with exposure of subchondral capitellar bone could avoid persistent lateral forearm pain, a main cause of prosthetic revision [9]. Moreover, the association with a press-fit textured–surfaced stem is designed to facilitate the bone ingrowth with direct bone formation within the pores or apposition of bone from the adjacent bone tissue into the porous zone [18]. Our current study reports satisfactory midterm clinical results with good to excellent MEPS score in 15 out of 17 patients (88%) with just two patients reporting fair results and no one reporting poor results. Out of the two patients who showed a fair MEPS (70), one sustained a transolecranon fracture-dislocation treated with two plates on the ulna and a single-screw fixation for the coronoid process, and the other met an early aseptic loosening of an uncemented stem 2 months after the surgery; both reported a deficient prono-supination out of the functional range of motion. No instances of elbow gross instability were found at the follow-up; ligament concomitant injuries were detected in 10 patients and treated with suture anchors or direct suture in 8 cases. A single case of lateral collateral ligament (LCL) lesion in a terrible triad was not treated and the overstuffed implant dislocated at 1 month with the need of external fixation and removal of the prosthesis (Fig. 1). Biomechanical efficacy in restoration of elbow stability of monopolar and bipolar prostheses is still a topic of debate; for some authors, the variable coupling between bipolar prosthesis and capitellar surface opposes the translation forces in a worse way if compared to monopolar implants, thus leading to residual elbow instability [19]. Chanlalit et. al [8] reproduced in a cadaveric study on 8 fresh-frozen elbow specimens terrible triad injuries, demonstrating that monopolar RHP ensures greater radiocapitellar stability than bipolar RHP and that the anatomic shaped head is preferable over the non-anatomic; the subluxation force of the bipolar prosthesis was significantly less (1 +/− 1 N) than monopolar non-anatomic implant (12 +/− 1 N) and anatomic monopolar design (16 +/− 1 N), and the native radial head is statistically comparable to the latter (18 +/− 2 N). On the contrary, Hartzel el al. [20] assessed instability of monopolar and bipolar prostheses in a cadaveric study after terrible triad simulated injury followed by LCL reconstruction: No differences were found in improving valgus and external rotation laxity. In vivo studies seem to support this hypothesis; in the presence of an intact or appropriately repaired LCL the risk of instability is not increased with bipolar design and a residual laxity is not translated in clinically evident instability of the elbow [21,22,23]. Despite we reported satisfactory clinical outcomes, the need of second surgery in 5 out of 17 patients is not neglectable, with an overall rate of 29.4% and a removal rate of 17.6%, higher than that reported in the current literature. Indeed, in a systematic review and meta-analysis, Kachooei et al. [24] found a pooled rate of radial head prostheses removal or revision of 10%; more than half of the implants were revised for excision of heterotopic ossifications (47%) and for the treatment of elbow stiffness and limitation of the range of motion (42%); other relevant causes were pain (19%), aseptic loosening (16%), overstuffing (13%) and instability (12%). In our series, the primary indication for removal was an early aseptic symptomatic loosening of the prostheses; after two months both patients presented type IV radiolucencies surrounding uncemented stems (Fig. 2). Flinkillä et al. [10], in a paper on survival of press-fit stems on 37 cases, found a rate of symptomatic loosening of 26.5% with severe osteolysis in 5 patients and severe proximal forearm pain in 6 cases; the mean time elapsed between the primary surgery and loosening was 11 months. Compared to smooth-stemmed prostheses where stable mild radiolucencies around the stem seem to be a common finding [25], osteolysis in press-fit stems is more pronounced [26]. In a recent systematic review on failures of radial head arthroplasties, press-fit RHPs failed statistically more often because of symptomatic aseptic loosening compared to intentionally loose-fit RHPs, with radiolucencies around the stems occurring early after implantation [27]; furthermore, subcollar resorption due to stress shielding in press-fit stems is common but it is typically minor and non-progressive [28]. It has been proved that proper stem size in uncemented implants is critical in preventing periprosthetic osteolysis and aseptic loosening. A proper bony contact, through an appropriate intramedullary fit, decreases excessive micromotion that can reduce bone ingrowth leading to the formation of a layer of fibrous tissue [1829]. In our experience, we have noticed that it is quite difficult to obtain the optimal press-fit and to choose the proper stem size in uncemented implants. Indeed, although a feeling of significant stability with press-fit system is often reached in the operating room, we think that axial and shear stresses produced by bipolar RHP during common daily activities may lead to early stem mobilization and symptomatic osteolysis. For this reason, in the last implanted prostheses, we preferred to use cementation which provides immediate primary stability and avoids the risk of neck fractures due to the insertion of the maximum-sized rasp. Analyzing our failures, we believe it is appropriate to investigate patients showing early severe radiolucencies because it often correlates to symptomatic aseptic loosening. Despite we found no significant relationship between grade of osteolysis and poor outcomes at the final follow-up, it is advisable to submit recurring checks to the patient; indeed, the onset of proximal forearm pain in press-fit RHP is a strong indicator for loosening, even in the absence of radiographic signs [30]. Our study has several limitations. It is retrospective in nature; the number of cases is relatively small, and the heterogeneity of associated injuries and concomitant treatments could affect the statistical power of our investigation. We were not able to assess the exact progression of radiological parameters, because plain radiographs were not carried out routinely between the postsurgical follow-up and our final follow-up. In conclusion, we believe that the use of bipolar implants in complex elbow injuries can be considered reliable if an accurate treatment of injured soft tissues is performed and if an optimal primary stability of the stem is reached, even with the use of cementation if needed; indeed, the role of soft tissues repair is strongly underscored in the most recent literature as instability represents one of the main causes of implant revision [24]. Most of the time, instability is related to LCL complex failure and lateral ligaments suture in addition to the radial head prosthesis can translate into much better outcomes (Fig. 3). Besides, the patient surveillance must be strict, since most failures occur within three years. Whereas early severe radiolucency is often a sign of implant failure, clinical relevance of late and progressive osteolysis still remains uncertain, as our statistical analysis shows, providing weak and not significant correlations with outcomes; further prospective studies with more homogeneous cohorts of patients are necessary to clarify this topic.

figure2
Fig. 2
figure3
Fig. 3

Availability of data and material

The authors confirm that the data supporting the findings of this study are available within the article. Further data that support the findings of this study are available from the corresponding author upon reasonable request.

References

  1. 1.Giannicola G, Sacchetti FM, Greco A, Cinotti G, Postacchini F (2010) Management of complex elbow instability. Musculoskelet Surg. 94(Suppl. 1):S25–S36. https://doi.org/10.1007/s12306-010-0065-8Article PubMed Google Scholar
  2. 2.Morrey BF, Tanaka S, An KN (1991) Valgus stability of the elbow. A definition of primary and secondary constraints. Clin Orthop Relat Res 265:187–195Google Scholar
  3. 3.Ring D (2011) Radial head fracture: open reduction-internal fixation or prosthetic replacement. J Shoulder Elbow Surg 20(Suppl. 2):S107–S112. https://doi.org/10.1016/j.jse.2010.11.011Article PubMed Google Scholar
  4. 4.Popovic N, Lemaire R, Georis P, Gillet P (2007) Midterm results with a bipolar radial head prosthesis: radiographic evidence of loosening at the bone-cement interface. J Bone Joint Surg Am 89:2469–2476. https://doi.org/10.2106/JBJS.F.00723Article PubMed Google Scholar
  5. 5.Mukka S, Sjöholm P, Perisynakis N, Wahlström P, Rahme H, Kadum B (2020) Radial head arthroplasty for radial head fractures: a clinical and radiological comparison of monopolar and bipolar radial head arthroplasty at a mean follow-up of 6 years. Eur J Trauma Emerg Surg 46(3):565–572Article Google Scholar
  6. 6.Pogliacomi F, Schiavi P, Pedrazzini A, Nosenzo A, Tocco S, Ceccarelli F (2015) Modified Mason type III and IV radial head fractures: results of different surgical treatments. Acta Biomed. 86(3):242–250PubMed Google Scholar
  7. 7.Beingessner DM, Dunning CE, Gordon KD, Johnson JA, King GJ (2004) The effect of radial head excision and arthroplasty on elbow kinematics and stability. J Bone Joint Surg Am 86(8):1730–1739. https://doi.org/10.2106/00004623-200408000-00018Article PubMed Google Scholar
  8. 8.Chanlalit C, Shukla DR, Fitzsimmons JS, An KN, O’Driscoll SW (2012) The biomechanical effect of prosthetic design on radiocapitellar stability in a terrible triad model. J Orthop Trauma 26(9):539–544. https://doi.org/10.1097/BOT.0b013e318238b3a2Article PubMed Google Scholar
  9. 9.Giannicola G, Sacchetti FM, Antonietti G, Piccioli A, Postacchini R, Cinotti G (2014) Radial head, radiocapitellar and total elbow arthroplasties: A review of recent literature. Injury 45:428–436. https://doi.org/10.1016/j.injury.2013.09.019Article PubMed Google Scholar
  10. 10.Flinkkilä T, Kaisto T, Sirniö K, Hyvönen P, Leppilahti J (2012) Short- to mid-term results of metallic press-fit radial head arthroplasty in unstable injuries of the elbow. J Bone Joint Surg Br 94(6):805–810. https://doi.org/10.1302/0301-620X.94B6.28176Article PubMed Google Scholar
  11. 11.Hotchkiss RN (1997) Displaced fractures of the radial head: internal fixation or excision? J Am Acad Orthop Surg 5(1):1–10. https://doi.org/10.5435/00124635-199701000-00001CAS Article PubMed Google Scholar
  12. 12.O’Driscoll SW, Jupiter JB, Cohen MS, Ring D, McKee MD (2003) Difficult elbow fractures: pearls and pitfalls. Instr Course Lect 52:113–134PubMed Google Scholar
  13. 13.Giannicola G, Greco A, Sacchetti FM, Cinotti G, Nofroni I et al (2011) Complex fracture-dislocations of the proximal ulna and radius in adults: a comprehensive classification. J Shoulder Elbow Surg 20(8):1289–1299. https://doi.org/10.1016/j.jse.2011.06.003Article PubMed Google Scholar
  14. 14.Ilahi OA, Bennett JB, Gabel GT, Mehlhoff TL, Kohl HW 3rd (2001) Classification of heterotopic ossification about the elbow. Orthopedics. 24(11):1075–1077CAS PubMed Google Scholar
  15. 15.Schneeberger AG, Adams R, Morrey BF (1997) Semiconstrained total elbow replacement for the treatment of post-traumatic osteoarthrosis. J Bone Joint Surg Am 79(8):1211–1222. https://doi.org/10.2106/00004623-199708000-00014CAS Article PubMed Google Scholar
  16. 16.Laun R, Tanner S, Grassmann JP et al (2019) Primary cemented bipolar radial head prostheses for acute elbow injuries with comminuted radial head fractures: mid-term results of 37 patients. Musculoskelet Surg 103(1):91–97. https://doi.org/10.1007/s12306-018-0576-2CAS Article PubMed Google Scholar
  17. 17.Pomianowski S, Morrey BF, Neale PG, Park MJ, O’Driscoll SW, An KN (2001) Contribution of monoblock and bipolar radial head prostheses to valgus stability of the elbow. J Bone Joint Surg Am 83(a):1829–1834. https://doi.org/10.2106/00004623-200112000-00010CAS Article PubMed Google Scholar
  18. 18.Pilliar RM, Lee JM, Maniatopoulos C (1986) Observations on the effect of movement on bone ingrowth into porous-surfaced implants. Clin Orthop Relat Res 1986:108–113Google Scholar
  19. 19.Allavena C, Delclaux S, Bonnevialle N, Rongières M, Bonnevialle P, Mansat P (2014) Outcomes of bipolar radial head prosthesis to treat complex radial head fractures in 22 patients with a mean follow-up of 50 months. Orthop Traumatol Surg Res. 100(7):703–709. https://doi.org/10.1016/j.otsr.2014.06.019CAS Article PubMed Google Scholar
  20. 20.Hartzler RU, Morrey BF, Steinmann SP, Llusa-Perez M, Sanchez-Sotelo J (2014) Radial head reconstruction in elbow fracture-dislocation: monopolar or bipolar prosthesis? Clin Orthop Relat Res 472(7):2144–2150. https://doi.org/10.1007/s11999-014-3672-0Article PubMed PubMed Central Google Scholar
  21. 21.Sershon RA, Luchetti TJ, Cohen MS, Wysocki RW (2018) Radial head replacement with a bipolar system: an average 10-year follow-up. J Shoulder Elbow Surg 27(2):e38–e44. https://doi.org/10.1016/j.jse.2017.09.015Article PubMed Google Scholar
  22. 22.Antoni M, Kempf JF, Clavert P (2020) Comparison of bipolar and monopolar radial head prostheses in elbow fracture-dislocation. Orthop Traumatol Surg Res 106(2):311–317. https://doi.org/10.1016/j.otsr.2019.10.027Article PubMed Google Scholar
  23. 23.Kodde IF, Heijink A, Kaas L, Mulder PG, van Dijk CN, Eygendaal D (2016) Press-fit bipolar radial head arthroplasty, midterm results. J Shoulder Elb Surg. 25(8):1235–1242. https://doi.org/10.1016/j.jse.2016.02.007Article Google Scholar
  24. 24.Kachooei AR, Baradaran A, Ebrahimzadeh MH, van Dijk CN, Chen N (2018) The rate of radial head prosthesis removal or revision: a systematic review and meta-analysis. J Hand Surg Am. 43(1):39–53.e1. https://doi.org/10.1016/j.jhsa.2017.08.031Article PubMed Google Scholar
  25. 25.Fehringer EV, Burns EM, Knierim A et al (2009) Radiolucencies surrounding a smooth-stemmed radial head component may not correlate with forearm pain or poor elbow function. J Shoulder Elbow Surg 18:275–278. https://doi.org/10.1016/j.jse.2008.09.012Article PubMed Google Scholar
  26. 26.Berschback JC, Lynch TS, Kalainov DM, Wysocki RW, Merk BR, Cohen MS (2013) Clinical and radiographic comparisons of two different radial head implant designs. J Shoulder Elbow Surg 22(8):1108–1120. https://doi.org/10.1016/j.jse.2013.02.011Article PubMed Google Scholar
  27. 27.Viveen J, Kodde IF, Heijink A, Koenraadt KLM, van den Bekerom MPJ, Eygendaal D (2020) Why does radial head arthroplasty fail today? A systematic review of recent literature. EFORT Open Rev. 4(12):659–667. https://doi.org/10.1302/2058-5241.4.180099Article PubMed PubMed Central Google Scholar
  28. 28.Chanlalit C, Shukla DR, Fitzsimmons JS, An KN, O’Driscoll SW (2012) Stress shielding around radial head prostheses. J Hand Surg Am. 37(10):2118–2125. https://doi.org/10.1016/j.jhsa.2012.06.020Article PubMed Google Scholar
  29. 29.Moon JG, Berglund LJ, Domire Z, An KN, O’Dricoll SW (2009) Stem diameter and micromotion of press fit radial head prosthesis: a biomechanical study. J Shoulder Elbow Surg 18:785–790. https://doi.org/10.1016/j.jse.2009.02.014Article PubMed Google Scholar
  30. 30.O’driscoll SW, Herald JA (2012) Forearm pain associated with loose radial head prostheses. J Shoulder Elbow Surg 21:92–97Article Google Scholar

Download references

Funding

Open access funding provided by Università degli Studi di Parma within the CRUI-CARE Agreement. All the authors (Nosenzo A, Galavotti C, Menozzi M, Garzia A, Pogliacomi F, Calderazzi F), their immediate family and any research foundation with which they are affiliated, did not receive any financial payments or other benefits from any commercial entity related to the subject of this article.

Author information

Affiliations

  1. Department of Surgery, Orthopaedic Clinic, Parma University Hospital, via Gramsci 14, 43100, Parma, ItalyAlessandro Nosenzo, Cristina Galavotti, Margherita Menozzi, Alice Garzia, Francesco Pogliacomi & Filippo Calderazzi

Contributions

All authors contributed to the study conception and design. Material preparation, data collection and data analysis were performed by Nosenzo Alessandro, Menozzi Margherita, Galavotti Cristina and Garzia Alice. The first draft of the manuscript was written by Nosenzo Alessandro and Calderazzi Filippo. All authors commented to previous versions of the manuscript. All authors read and approved the final manuscript.

Corresponding author

Correspondence to Alessandro Nosenzo.

Ethics declarations

Conflict of interest

The authors declare that they have no conflict of interest.

Ethics approval

The study was approved by the Regional Ethic Committee with number of protocol 11396.

Consent to participate

All the patients provided written informed consent upon the study enrollment.

Consent for publication

All the patients provided written informed consent for the publication of any associated data and accompanying images.

Additional information

Publisher’s Note

Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.

Open Access This article is licensed under a Creative Commons Attribution 4.0 International License, which permits use, sharing, adaptation, distribution and reproduction in any medium or format, as long as you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons licence, and indicate if changes were made. The images or other third party material in this article are included in the article’s Creative Commons licence, unless indicated otherwise in a credit line to the material. If material is not included in the article’s Creative Commons licence and your intended use is not permitted by statutory regulation or exceeds the permitted use, you will need to obtain permission directly from the copyright holder. To view a copy of this licence, visit http://creativecommons.org/licenses/by/4.0/.
